Eisele Submersible agitator
Eisele submersible manure mixers have been supplied since 1982. They are used in cellars, silos, manure bags, folio basins and biogas reactors. The latter in an explosion-free version.
Eisele is responsible for the design and manufacture of the entire mixers. Both the electric motor and the planetary transmission are produced in-house. The manure mixers are fitted with a ceramic seal as standard and are IP 68 protected. The chamber where the supply cable leaves the mixer is fitted with a leakage protection device. To protect the manure mixer against overloading, the windings of the electric motor are equipped with a thermal contact.
The manure mixers are available in 2.2 to 22.5kW versions. The stirring wing ranges from Ø29 to Ø100 cm for the heaviest version.
Control can be easily carried out with a manual turn switch to fully automated.
